Magnelab Solid-Core AC Current Sensor UCT-1250-100 measures current up to 100 Amps. 1.25 inch Opening.

Magnelab UCT models are better than one percent accuracy and less than one degree phase angle. Output is controlled by a precision resistor fixed at the industry standard of 0.333 Volt AC. The rugged epoxy encapsulated construction comes with eight feet twisted leads. Please contact Magnelab for other ratings and customized designs.

Features:

• Rated input current 100 Amps
• Output 0.333 Volt AC at rated current
• Phase angle < 1 degrees measured at 50% rated current
• Linearity accuracy ± 1%
• Accuracy at 10% to 130% of rated current
• 8 ft. twisted-pair lead
• Custom output and other parameters are available
• UL recognized
